Características de LD Systems DAVE 8 roadie
- Type: active
- Colour: black
- Max. SPL (continuous): 117 dB
- Max. SPL (peak): 123 dB
- Frequency response: 45 - 19000 Hz
- Dispersion (H x V): 60° x 60°
Subwoofer
- Woofer dimensions 8"
- Woofer dimensions: 203 mm
- Woofer magnet: Ferrite
- Woofer brand: Custom made
- Woofer voice coil: 1,5"
- Woofer voice coil: 38,1 mm
- Cabinet construction: Bandpass
- Cabinet material: MDF
- Cabinet / Housing surface: painted
- Subwoofer width: 345 mm
- Subwoofer height: 430 mm
- Subwoofer depth: 460 mm
- Subwoofer features: Limiter, threaded flange M20, handles handles
- Subwoofer weight: 20,7 kg
Mid/Hi System
- Midrange size: 2 x 4"
- Midrange size: 2 x 101,6 mm
- Midrange magnet: Ferrite
- Midrange brand: Custom made
- Midrange voice coil: 1"
- Midrange voice coil: 25,4 mm
- Horn: radial
- Tweeter dimensions: 1 "
- Tweeter dimensions: 25,4 mm
- Tweeter magnet: Ferrite
- Tweeter brand: Custom made
- Tweeter voice coil: 1"
- Tweeter voice coil: 25,4 mm
- Mid/Hi system impedance: 4 ohms
- Loudspeaker inputs: 1
- Speaker input connections: Speakon compatible
- Mid/Hi system cabinet construction: closed
- Mid/Hi system cabinet material: MDF
- Mid/Hi system cabinet surface: painted
- Mid/Hi system width: 150 mm
- Mid/Hi system height: 350 mm
- Mid/Hi system depth: 170 mm
- Mid/Hi system features: 16 mm flange, metall front grille, transport handle
- Mid/Hi system weight: 4,2 kg
Amplifier Module (integrated in Subwoofer)
- Amplifier: Class A/B
- Amplifier Output System (RMS): 350 W
- Amplifier Output System (Peak): 1400 W
- Protection circuits: short circuit, limiter, overload
- Cooling: heat sink
- Controls: ON/ OFF, Sub Level, Main Level, MP3 / Hi-Z Level, Mic Level, Line Level, input switch (MP3 / Hi-Z), 180° Phase Reverse
- Display: Power, Protect
- Operating voltage: 220 V AC - 240 V AC
- Line inputs: 3
- Line input connectors: XLR/ 6,3 mm jack, RCA, microphone, MP3 / Hi-Z
- Mic inputs: 1
- Mic input connectors: XLR/ 6,3 mm jack
- Instrument inputs: 1
- Instrument input connectors: 6,3 mm jack
- Loudspeaker outputs: 2
- Speaker output connections: Speakon compatible -- Nota: Este producto NO incluye Cables Speakon
